HTHA detection and sizing

HTHA

What is HTHA?

HTHA or High Temperature Hydrogen Attack is damage caused through hydrogen atoms diffusing into steels that are exposed to high pressure hydrogen at elevated temperatures, typically above 400°C. The hydrogen reacts with the carbon and forms methane gas within the steel. This process leads to fissuring and decarburization causing loss of tensile strength and can be the cause of a sudden catastrophic failure.

Our advanced HTHA detection and sizing course is designed to educate Advanced UT inspectors in methodologies and techniques to more reliably detect HTHA. This course is founded on extensive work and experience gained during industrial trials as part of the E2G HTHA JIP. Lavender International are custodians of the extensive E2G sample inventory and this will be used for HTHA training and certification purposes.

“ I found the whole course very well run with a good set up. My tutor, Rachel was excellent, very knowledgeable, helpful and approachable. ”

- A student who attended one of our Penetrant Testing course in March 2023.

Course Content:
The level 2 advanced course will address the following issues;

The course will contain in depth training on advanced UT applications, fine tuning of equipment parameters and data acquisition from a variety of thickness and states of material degradation.
Data analysis will consist of many forms of raw ultrasonic data including TOFD, PAUT and backscatter data.
Velocity ratio, attenuation and frequency analysis will also be addressed.
Damage mechanisms of HTHA ranging from colonies of microscopic damage to through wall cracks will be experienced.
Characterization of material degradation is a critical part of this course. Sources of false positives will be discussed, material inclusions, stepwise HICC damage and weld back cladding issues are also included.

The course will involve hands on testing as well as theoretical approach and offline data analysis tutorials.

Pre-requisite
Trainees should ideally hold Level 2 TOFD and PAUT certification.

“ I found the whole course very well run with a good set up. My tutor, Rachel was excellent, very knowledgeable, helpful and approachable. ”

- A student who attended one of our Penetrant Testing course in March 2023.

Lavender International do not generally perform site inspections. We do however provide company support by assisting in fine tuning inspection set-ups and overseeing data analysis, and where necessary support specialist applications. Please contact our USA Office Manager, James Wilson, for more information.

“ I found the whole course very well run with a good set up. My tutor, Rachel was excellent, very knowledgeable, helpful and approachable. ”

- A student who attended one of our Penetrant Testing course in March 2023.

HTHA Detection and Sizing courses are available at our training centres in Houston, TX and the Advanced Manufacturing Park in Sheffield.

UK office – Penistone	USA office – Houston, Texas	On-site locations
Click here for available dates	Click here for available dates	Contact us

If you would like further information about this course, please contact us.

“ I found the whole course very well run with a good set up. My tutor, Rachel was excellent, very knowledgeable, helpful and approachable. ”

- A student who attended one of our Penetrant Testing course in March 2023.

Scientific Calculator
Safety Boots
Overalls/Lab Coat
Tape Measure

All other equipment and training materials are provided by Lavender International.
Protective gloves, protective eye glasses and plastic aprons are also available for the use of students.

“ I found the whole course very well run with a good set up. My tutor, Rachel was excellent, very knowledgeable, helpful and approachable. ”

- A student who attended one of our Penetrant Testing course in March 2023.
